Marin Bikes Gravel Bike | DSX 1, for Gravel, Adventure

Rs. 82,999.00
Tax included. Shipping calculated at checkout.
Shop securely for thousands of cycling products online in India Shop online securely for thousands of cycling products in India
Ordering Assistance Helpline:
Please speak with our support team on +919538949110 for any guidance while ordering. Product Country of Origin: Taiwan.

Long-Distance Mixed Surface Commuting
Gravel Riding - Adventure on And Off-Road Riding
The DSX is the mountain biker’s gravel bike with familiar hand positioning, reliable 1x drivetrains, large tire clearance, and dropper post routing for better off-road control, and on-road descending stability.

  • Wheel: SIZE: 700C
  • Frame: Aluminum
  • Size Range: S, M, L, XL

Size Rider height range
S 5'3" to 5'6"
M 5'6" to 5'10"
L 5'10" to 6'2"
XL 6'2" to 6'4"

Additional Shipping Charges Apply:
This shipment originates from our distribution center in Bangalore, India. Any orders received out of Bangalore will attract a nominal shipping charge, to be decided after the order is placed and when the product is ready for dispatch - by checking the volumetric weight of the shipment box. Applicable shipping charges by the transporter will be communicated and to be paid before the dispatch.

  • Frame: Series 3 DSX, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard, and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
  • Fork: Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
  • Rims: Marin Aluminum Double Wall, 21mm Inner, Disc Specific
  • Hub, Rear: Forged Aluminum Alloy, 142x12mm, 32H
  • Hub, Front: Forged Aluminum, 100x12mm, 32H
  • Spoke, Nipples: 14g Black Stainless Steel
  • Tires: WTB Riddler, 700Cx45mm
  • Derailleur, Rear: Shimano Deore 11-Speed
  • Derailleur, Front: -
  • Shift Lever: Shimano Deore 11-Speed
  • Crankset: Forged Aluminum, 42T Steel Narrow Wide Chainring
  • Bottom Bracket: Sealed Cartridge
  • Chain: KMC X11
  • Cassette: Sunrace 11-Speed, 11-51T
  • Brake, Front: Tektro HD-R280 Flat Mount Hydraulic Disc, 160mm Rotor
  • Brake, Rear: Tektro HD-R280 Flat Mount Hydraulic Disc, 160mm Rotor
  • Brake Levers: Tektro Hydraulic
  • Handlebar: Marin MiniRiser
  • Stem: Marin 3D Forged Alloy
  • Grips: Marin MTB
  • Headset: FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
  • Seatpost: Marin Alloy
  • Saddle: Marin DSX
  • Pedals: Commute Platform
  • Extras: Bolt-On Thru-Axles F and R


Series 3 Frame
The DSX features a butted and formed Series 3 6061 aluminum frame with internal routing, 142x12mm thru-axles, flat mount disc brakes, and rack and fender eyelets.


Tire Clearance
The DSX comes stock with 700x45mm tires, with room for 29x2.1” knobbies.


Disc Brakes
The DSX features the latest flat mount disc brake standard for smooth, controlled stopping in all conditions with minimal maintenance.


Dropper Post Routing
Dropper posts are quickly becoming standard fare for gravel racers and riders that spend significant time on rough surfaces, and the DSX features internal dropper post routing for easy upgrades.


Geometry and Size Guide


Stack 544.4 572.5 600.6 628.7
Reach 380 405 420 435
Headtube Angle 69.5° 69.5° 69.5° 69.5°
Headtube Length 120 150 180 210
Seattube Angle 74° 74° 74° 74°
Seattube Length 430 480 520 558
Toptube Effective 536.1 569.2 592.2 615.3
BB Height 279.5 279.5 279.5 279.5
BB Drop 80 80 80 80
Chainstay 425 425 425 425
Wheelbase 1024.42 1060 1085.4 1110.9
Standover Height 658.76 700.51 730.39 758.5
Fork Offset 50 50 50 50
Seatpost Diameter 27.2 27.2 27.2 27.2
Handlebar Width 640 680 680 680
Stem Length 70 70 70 70
Crank Length 170 170 175 175

* All lengths in millimeters
