Shimano Bottom Bracket, Press Fit | XTR SM-BB93, Hollowtech II - Cycling Boutique
Sold Out
  • SKU: CB4547

Shimano Bottom Bracket, Press Fit | XTR SM-BB93, Hollowtech II

Rs. 3,430.00
Tax included. Shipping calculated at checkout.
Shop securely for thousands of cycling products online in India Shop online securely for thousands of cycling products in India
Ordering Assistance Helpline:
Please speak with our support team on +919538949110 for any guidance while ordering. Product Country of Origin: Taiwan.

The Pro-Level engineering built quality of Shimano XTR - Robustness and incredibly durable and smoothness in XTR SM-BB94-41 bottom bracket for Press Fit

The Shimano XTR is every thrill-seeking mountain biker's hit list - known for world tour-ready reliability to being novice budget racer friendly. The XTR SM-BB94-41 is for press fit installation allowing Hollowtech II-compatible cranks with 24 mm axles to be mounted on MTB frames with bottom bracket widths measuring 68 mm or 73 mm case. The shells and sleeve of the durable press-fit bottom bracket are made of plastic, for Pro level usage. The small ball bearings are impressively lighter by 20 grams lighter than their predecessor.



SHIMANO XTR - Bottom Bracket - Threaded - HOLLOWTECH II - 68/73 mm shell width

With smooth rotation and better sealing performance, the SHIMANO XTR bottom bracket is durable for mountain bike usage. It is available in threaded and press-fit options.

  • Application: Cross Country, All Mountain, Enduro
  • Series: XTR
  • Type: BSA
  • Shell Width: 68 mm / 73 mm
  • Axle Diameter: 24 mm (Hollowtech II)

Technical Information:
  • Bearings: Steel
  • Bottom Bracket Cup Material: Aluminum
  • Bottom Bracket Centre Tube Material: Aluminum

  • XTR FC-M980, FC-M985, FC-M9000, FC-M9020, FC-M9100, FC-M9120, FC-M9130
  • FC-MT900

  • 19.3 g lighter than the predecessor SM-BB90-A
  • small ball bearings for low weight
  • smooth rotation
  • improved seal for long durability: specially developed for MTB use
  • anodized bearing cups and sleeves

Package Contents:
  • 1 x Shimano SM-BB93 right bearing cup, with bearings
  • 1 x Shimano SM-BB93 left bearing cup, with bearings
  • 1 x Shimano bottom bracket sleeve
  • 3 x space


Hollowtech II
Shimano Hollowtech II is a crank bottom bracket system designed to achieve an ideal ratio of stiffness, weight, and rotational efficiency. It is based on an integration of the bottom bracket and the right crank arm and works with a 24 mm axle or bearing diameter, which has proven to be optimal in terms of stability. In many cases, the bearing cups are on the outside so that the load is better distributed. High-quality precision seals ensure long service life.

Product Specifications
  • SERIES: XTR M9000 Series
  • Average weight: 73
  • Threaded BB shell width_73mm: ✔
  • HOLLOWTECH II bottom bracket_Threaded bottom bracket type: ✔
  • A small ball bearing: ✔
  • Threaded BB shell width_68mm: ✔
  • Threaded bottom bracket shell width (mm)_68: ✔
  • Threaded bottom bracket shell width (mm)_73: ✔


*Note: Images are for representational purposes only. Actual size / packaging varies with product type/size.
