SRAM Rear Derailleurs | Eagle-XX1, 12-Speed

This new derailleur not only answers the Eagle™ drivetrain’s need for greater capacity, but is also the next evolution of our proven 1x-specific X-HORIZON™ design. The larger, 14-tooth X-SYNC™ lower pulley, allows 10- to 50-tooth cassette capacity in this compact design and also adds to Eagle’s overall smooth-pedaling feel. Our new, Type-3 ROLLER BEARING CLUTCH™ features a smoother torque curve for a quieter, more consistent operation and feel. CAGE LOCK™ has been moved back and out of the way, protecting it from trail debris. A redesigned, robust mounting system further improves the Eagle™ derailleur’s performance and overall durability.

Features

• Completely redesigned rear derailleur incorporating our proven X-HORIZON™ design and new Type-3 ROLLER BEARING CLUTCH™ technology
• Re-engineered mounting system and repositioned CAGE LOCK™ add robustness
• Eagle™ pulley technology provides greater efficiency, crisper shifting and quieter operation
• Carbon cage and lightweight hardware make it light and tough.

Technology

Cage Lock
With CAGE LOCK™ technology in the rear derailleur, wheel removal and installation—as well as chain installation—becomes faster and simpler. Just push the cage forward to create slack and lock it into place.

Roller Bearing Clutch
Roller Bearing Clutch™ rear derailleurs deliver maximum drivetrain stability—even through the most punishing terrain. With ROLLER BEARING CLUTCH™ technology, derailleur bounce and chain slap are eliminated without sacrificing precision.

X-Actuation
Developed specifically for SRAM 1x™, X-ACTUATION™ keeps shifting sharp and consistent across the entire cassette.

X-Horizon
The X-HORIZON™ rear derailleur’s ‘straight parallelogram’ design limits all movement to the horizontal axis, which makes ghost shifting impossible while also reducing shift force. For quicker, more exact shifting, the large upper pulley offset design maintains a constant chain gap across all gears.

X-Sync
SRAM X-SYNC™ 1x chain rings provide the highest level of performance and durability. The SRAM X-SYNC™ tall square teeth edges engage the chain earlier than traditional triangle-shaped teeth. The sharp and narrow tooth profile, as well as rounded chamfer edges, help manage a deflected chain. To provide the best possible performance in muddy conditions, the X-SYNC™ chain rings have been designed with mud-clearing recesses for the inner chain links and rollers. Engineered in Germany, X-SYNC™ rings are an integral part of the SRAM 1x™ drivetrain.

Specifications

• Speeds: 12
• Material: Forged aluminium and carbon fibre
• Colors: Black, Gold
• Outer Cage: Carbon fibre
• Compatibility: Eagle™ 10-50t only
• Inner Cage: Forged aluminium
• Spring: Titanium
• Bearings: Stainless
• Cage Sizes: Eagle™
• Mount Options: New improved B-Bolt attachment improves RD durability and consistency.
• Max Tooth: 50
• Pulleys: Eagle™ chain compatible
• Pull: X-ACTUATION™
• Technology Highlight(s): X-HORIZON™, X-ACTUATION™, X-SYNC™, ROLLER BEARING CLUTCH™, CAGE LOCK™
• B Knuckle: The new B-Bolt attachment method reduces noise and improves durability
• Other: Type 3 ROLLER BEARING CLUTCH™

SKU# 00.7518.095.000
